IP68 DC5V 12mm Square F8 RGB LED WS2811 Full Colors Digital Pixels Strings

60LED WS2811 Addressable led strips
IP68 DC5V 12mm Square F8 RGB LED WS2811 Full Colors Digital Pixels Strings


12mm WS2811 UCS1903 SM16703 Full Color LED Pixel For Art Sign, Give full play to the advantages of LED point light source, any combination, let LED external luminous characters, large outdoor LED advertising signs, LED electronic light box production easier. Special bayonet design, direct installation after punching, installation time is fast. Full-color light string, using an intelligent control system, can produce gradient, jump, chase, scan, display animation, and other effects, and can achieve asynchronous and synchronous control, randomly arranged to meet different user requirements.

Data sheet:

  Product:   IP68 DC5V 12mm Square F8 RGB LED WS2811 Full Colors Digital Pixels Strings
  Item No.:    WTP-SP-2811-1205
  LED:    F8 RGB, 50led/string
  View angle:   160°
  IC Chip:   WS2811 UCS1903 SM16703
  Input voltage:   5V
  Power:   15w/m
  Size:   OD=12(mm), 50pixels/string


1) Individually control: 1PCS LED pixel & 1IC
2) IC chip: can be ws2801, ws2811, ucs1903, sm16703 IC .
3) Waterproof: IP68, with full silicon glue waterproof protection.
4) Installation: Easy to install, you’d better drill the hole with 12mm.
5) With features of high brightness, low power dissipation, long lifespan, low Voltage, low decline, colorful.
6) Power supply: A 5V DC power supply to power this pixel is required, do not use higher than 6V or you will destroy the entire pixel.
7) Connetors: 3PIN or 4PIN JST female and male connectors.
    Each led pixel is seperate, you can connect them one by one via male and female connectors easliy.
    3PIN: DAT, DC5V+, GND-
    4PIN: DAT, CLK, DC5V+, GND
8) Factory sales directly, good quality and price, offer 2 years warranty and quikly after-sale service.
9) Color and effect: addressable lights, you can set to any color, or animate, like running water, chasing
and scanning etc. depending on the different installation methods may compose different dynamic effect of different color’s character and design


> Widely used for home decoration use, hotels, clubs, shopping malls
> Architectural decorative lighting, boutique atmosphere lighting
> Extensively applied in background lighting, concealed lighting, channel letter lighting
> Emergency & security lighting, advertisement sign lighting
> Decorative lights for holiday, event, show exhibition
> Applicable for automobile and bicycle decoration, border or contour lighting


1) Do not use any acidic, alkaline adhesive fixing Product;
2) It is prohibited to make products with a hard object collision, friction;
3) Do not use your fingers to press LED;
4) Don’t make positive and negative reversed;
5) Don’t install when product is working;
6) Installation, repair and maintenance must be made by professional Person;
7) Before you use them make sure the power supply voltage to meet the requirements and wire connection correctly.

 Order Info: (IP20/IP65/IP67/IP68)

SN Model Number LED Qty
PCB Width
Unit Price
1  WTP-SP-2811-1205 50 12 10cm 5V 15 US$9.3/string
2  WTP-RP-2811-1205 50 12 10cm 5V 15 US$5.0/string
3  WTP-RP-2801-1205 50 12 10cm 5V 15 US$14/string
3  WTP-RP-2811-1212 50 12 10cm 12V 30 US$11/string
